- Jun 24, 2020 Well, I reinstalled Mojave. Didn't help anything. I then removed the PCI SSD card in my office Mac Pro 5,1. It's a different brand than the Apricorn Velocity Solo x2. This one is a Sedna PCI Express (PCIe) SATA III (6G) SSD Adapter (also from Amazon). The problem apparently was the card not working with the Option key.
- Hi guys, I bought my mac pro 5.1 and mac has already had mojave on HDD and ssd. So, I used my mac, but I need to erase my HDD, cause I needed to have free place on my hard drive. Now, I want to have extra mojave on my HDD for safety. (If my ssd will broke) I cant install mojave, because I.
So we received a couple of Mac Pro 1,1′s which were having issues and decided to see what we could make from them. The idea being to make a powerful, modern Mac as cheaply as possible. The Mac Pro 1,1 is a great place to start – it has masses of internal expansion, and can be grabbed cheaply second hand sources, often for less than £ 100.
The basic issue with the Mac Pro 1,1 is that as factory setup and running it will not run above Mac OS 10.7.5 – this limits it’s usability; especially with Applications like Adobe CC or even modern apps like Photos or iTunes. It also limits some upgrade options; especially with Graphics cards like our R9 – as these earlier OSes do not have the drivers needed.
Jun 04, 2018 The 4,1/5,1 Mac Pro just won again. They will be the only Pre-2012 Macs to run Mojave with no hacks, cracks, or scripts. The only asterisked footnote was 'with Metal Capable GPU'. Wonder where you could get one of those? Well of course our GTX1080Ti will do, but not everyone needs that much horsepower.
To start with much of this work has been done by others; I will try and link back to sources as much as possible. That said many people have done similar things in different ways – so I will try and justify my methodology as well (or at least explain the logic behind the decision).
The short short version:
1) Upgrade the firmware to Mac Pro 2,1 (add support for newer CPUs)
2) Upgrade the CPUs to 2 x Quad Core 3.0Ghz Xeons.
3) Upgrade the RAM to above 16GB (we went to 32GB but anything above 16GB should be fine)
4) Install 4 x HDDs (defiantly Matched in size – preferably matched in brand, model etc) – Setup as a RAID 0 – and Test.
5) Upgrade the Graphics Card (we used our R9) – you need to have at least 512 MB VRAM.
6) Install Mac OS X 10.11.6 onto the RAID and modify the boot.efi and <supported platforms> list
7) Boot and enjoy!!
So these steps in detail – with reasons and processes.
Mac Pro 5 1 Mojave Video Card
1) Upgrade the firmware to Mac Pro 2,1 (add support for newer CPUs)
There is a useful forum here: which has a utility to do this. I followed the instructions and rebooted with the long tone and off you trot! This is needed to add support for the newer CPUs we had in store.

2) Upgrade the CPUs to 2 x Quad Core 3.0Ghz Xeons.
We had these in store from a failed Mac Pro 2,1 which had logic issues – but they can be purchased from eBay very cheaply – there is a great list here on MacRumors which can help you decide which suit your budget / needs. If you want to run lots at any one time then going from Dual Core to Quad Core can be helpful (I wanted to get virtualization working to support legacy OSes at the same time) – otherwise going for higher clock speed is more helpful for processes such as video encoding.
3) Upgrade the RAM to above 16GB (we went to 32GB but anything above 16GB should be fine)
If you trust the second hand market; you can pick up some real bargains for 667mhz RAM for these Machines (we do see some customers with issues from second hand RAM but would image it is a small number given how much it appears on eBay etc) – we do sell new modules here.
You MUST have above 12 GB RAM to run El Capitan without it falling over at random intervals – when we had it up and running with 8GB (waiting for a stock delivery) it would fall over every 10 mins or so at random times – since the upgrade it is up for days without any bother.
4) Install 4 x HDDs (defiantly Matched in size – preferably matched in brand, model etc) – Setup as a RAID 0 – and Test.
I had 4 x 3TB HDDs from a previous project which were no longer being used – a bit of a miss match of brands (a pair of Seagate 3TB, and a pair of WD Green 3TB drives). Once these were installed in the Mac Pro I used Target Disk mode via Firewire to a Mac Mini and setup as a RAID 0 using SoftRAID. Using target mode meant that we could install the latest SoftRAID drivers and not have issues later with older versions etc.
This RAID gives over 500MB/s read and write speed (as tested with BlackMagic Disk Speed Test) – and you could expect more with newer and matched drives. Not bad for 12TB of storage!
I used RAID 0 as this Mac will be backed up to a Time Machine server and also be acting as a Media Backup – so failure accounted for.
5) Upgrade the Graphics Card (I used our R9) – you need to have at least 512 MB VRAM.
Video Cards with less than 512 MB VRAM cause issues on these early Mac Pros with the later OSes. I replaced the stock GT with a flashed R9 270x 2GB VRAM. Other cards will work; however the 270x is within the Max power draw spec, has nice out of the box driver support in 10.11.6 and full Dual-link DVI.
6) Install Mac OS X 10.11.6 onto the RAID and modify the boot.efi and <supported platforms> list
I used the Mac Pro in Target disk mode attached to a 2012 Mac Mini running 10.9 – this allowed me to install 10.11.3, create an account and complete all the usual upgrades to 10.11.6 so that I knew it was a fully working install. – Effectively using the Mac Pro as a big hard drive enclosure!
Once it was all working I booted back into the Mac Mini and followed the instructions here:
This involved replacing the boot.efi and adding a line item to the <supported devices> plist. (I went for grey as I am a traditionalist!).
A tentative reboot with the “Alt” key and the 10.11.6 RAID appeared – selected and then the login appeared! It lives! Make sure that the hard drive is selected in the startup disk panel to avoid a long delay on boot and it has been up and running ever since!
So now I have a Mac Pro, running El Capitan 10.11.6 with 32GB RAM, 12TB hard drive operating at similar speeds to a modern SSD, the wonderful R9 270X with 2GB VRAM and two displays. Daily it runs four web browsers with approx 10 tabs in each, Parallels with various older OSes from 10.6.8 server upwards, Photos, eMail, Facetime (with a USB webcam), iTunes, iWork and all the usual office tasks and all for less than the cost of a iPad!
This article applies only to video cards that originally shipped with a specified Mac Pro or were offered as an upgrade kit by Apple. Similar cards that were not provided by Apple may have compatibility issues and you should work with the vendor of that card to confirm compatibility.
Mac Pro (2019)
Learn more about cards you can install in Mac Pro (2019) and how to install PCIe cards in your Mac Pro (2019).
Mac Pro (Late 2013)
- Dual AMD FirePro D300
- Dual AMD FirePro D500
- Dual AMD FirePro D700
Mac Pro (Mid 2010) and Mac Pro (Mid 2012)
- ATI Radeon HD 5770
- ATI Radeon HD 5870
Learn about graphics cards supported in macOS 10.14 Mojave on Mac Pro (2010) and Mac Pro (Mid 2012).
Mac Pro (Early 2009)
- NVIDIA GeForce GT 120
- ATI Radeon HD 4870
- ATI Radeon HD 5870, offered as an upgrade kit
The Radeon HD 5870 card requires Mac OS X 10.6.4 or later and the use of both auxiliary power connections.
Mac Pro (Early 2008)
Mac Pro 5 1 Graphics Card Upgrade Mojave
- ATI Radeon HD 2600 XT
- NVIDIA GeForce 8800 GT (part number 630-9191 or 630-9897)*
- NVIDIA Quadro FX 5600
- ATI Radeon HD 4870, offered as an upgrade kit
The Radeon HD 4870 card requires Mac OS X 10.5.7 or later.
Mac Pro (Original)
Mac Pro 5 1 Video Card Upgrade For Mojave Free
- NVIDIA GeForce 7300 GT
- ATI Radeon X1900 XT
- NVIDIA Quadro FX 4500 (part number 630-7532 or 630-7895)*
- NVIDIA GeForce 8800 GT (part number 630-9492), offered as an upgrade kit.*
The NVIDIA GeForce 8800 GT card requires Mac OS X 10.5.2 or later with the Leopard Graphics Update 1.0 or the computer may not start up properly.
Mac Pro 5 1 Video Card Upgrade For Mojave 2
* To identify a graphics card part number, check the label on the back of the card.
